C H A P T E R 3 O S D M E N U A N D C O N F I G U R A T I O N

4. Increase RIGHT scale value by 20. AREA1 position after change is: TOP: 30,

DOWN: 45, LEFT: 20 and RIGHT: 60.

5. Increase LEFT scale value by 20. AREA1 position after change is: TOP: 30, DOWN:

45, LEFT: 40 and RIGHT: 60.

In order to save the changes and complete the setting, press the mini-joystick.

This allows you to return to the previous menu.

3.3.8.6 MIRROR

-ON: Sets a horizontal image 180 angel inversion.
-OFF: Disable the inversion.

3.3.8.7 SHARPNESS

The contour of the video image becomes cleaner and more distinguishing as the level of
SHARPNESS increases. If the level goes up extremely, it may affect the video image and
cause noise.
-ON: Enable the SHARPNESS mode.

SPECIAL

CAMERA ID OFF
COLOR ADJ. <┘
SYNC. INT
MOTIION DET OFF
PRIVACY OFF

> MIRROR OFF

SHARPNESS ON <┘

RESET

RETURN <┘

AREA1
