2 adjusting camera position – EverFocus EZ550 User Manual
Page 19
C H A P T E R 2 I N S T A L L A T I O N
18
10. Close the back cover and screw the 2 screws firmly. Now, you are done with the
installation.
NOTE: Before you close the cover, please make sure control key is attached firmly and
wire doesn’t stuck.
2.2 Adjusting Camera Position
Adjust camera’s angle vertically or horizontally by using hex key included in package.
Screws for back panel
Loose this screw to make
angle adjustment vertically
