Electrolux EN3700AHW - Manual (Page 17)

B2
B1
• Remove the hole covers (B1) by driving
a drift into them and rocking them
loose.
• Unscrew the middle hinge (B2) and in-
stall it on the opposite side.
• Install the hole covers provided within
the accessory bag.
• Install the upper door and screw the
upper hinge.
• Install the lower door and screw the
lower hinge by changing the position of
the pin.
• Tighten the pin. Make sure that the
doors are aligned and blocked by the
lock-nut
• Raise the appliance and install the ven-
tilation grille.
• Unscrew the handle. On the opposite
side remove the hole covers by driving
a 3–4 mm drift or drill into them. Install
the handle.
• Install the hole covers provided within
the accessory bag.
• Put the cabinet in position.
WARNING!
Reposition, level the appliance,
wait for at least four hours and
then connect it to the power
socket.
Do a final check to make sure that:
• All screws are tightened.
• The magnetic seal adheres to the cabi-
net.
• The door opens and closes correctly.
WARNING!
If the ambient temperature is cold
(i.e. in Winter), the gasket may not
fit perfectly to the cabinet. In that
case, wait for the natural fitting of
the gasket.
8. NOISES
There are some sounds during normal
running (compressor, refrigerant circula-
tion).
ENGLISH 17
