Emotiva IPS-1 Integrated Power Amplifier

Integrated-Modular Power Amplifier Features

• A true audiophile quality power amplifier
• 150 Watts x 7 into 8 Ohms
• 200 Watts x 7 into 4 Ohms
• Completely stable into 2 ohm loads
• Each channel features independent 250VA, low noise toroid power transformers w/ high speed rectifiers

and low ESR 105°C filter capacitors

• High efficiency Class H power amplifier design, minimizes power losses and allows cool and efficient

operation

• Complementary, discrete power amplifier design incorporating high current, high speed, Toshiba power

devices

• RCA inputs
• 5 Way Binding Post speaker outputs
• Silent turn on/off - No audible transients
• THD less than .015%, 20Hz-20kHz with 80kHz measurement bandwidth
• DC offset, less than 1mv, servo controlled.
• Crosstalk between ANY two channels – greater than 120dB
• All aluminum capacitors are premium quality, low ESR, 105°C rated for high reliability and perfor-

mance

• Doubled sided, plate through, glass epoxy, FR4 PCB’s used throughout with 2 ounce poured copper on

all power sections and ground planes

• Individual channel status indicators for standby, operate, and fault behind tinted acrylic panel
• Fully protected from all fault conditions
• Soft start circuitry
• Signal sensing auto turn-on or remote 12 VDC trigger.
• Soft touch power switch
• 3RU chassis w/ solid milled aluminum faceplate
• IEC power inlet, 120 VAC-60Hz
