Rated Power Output:

@120VAC

@ 1% THD 8 Ohms:

150W RMS x 7

@ 0.1% THD 8 Ohms:

140W RMS x 7

@ 1% THD 4 Ohms:

200W RMS x 7

@ 0.1% THD 4 Ohms:

175W RMS x 7

Stable to 2 Ohms

Frequency Response:

+/- 0.1 dB:

20 Hz-20 kHz

+/- 3 dB:

10 Hz-100 kHz

Signal to Noise Ratio
(Un-weighted):

105 dB

Distortion (THD):

(20Hz-20kHz):

<0.015%

80kHz Measurement Bandwidth


Damping Factor:

(into 8 Ohms):

>300

Gain:

(1.7V Sensitivity):

+27dB

Input Impedance:

>20K Ohms

External Trigger: 5-24VDC

DC Offset: Less than 1mv
Servo controlled

Crosstalk:
Between ANY channels >120dB

Electrical Requirements

120VAC-60Hz or

240VAC, 50-60Hz

2200 Watts

Power Consumption
(Standby)

3 Watts

(At Idle)

55 Watts

Dimensions
IPS-1w/Feet

17”Wx6Hx16”D

Chassis Type

3RU chassis

Raw Weight

69.5 lbs (31.6 kg)

Shipping Weight

82.5 lbs (37.5 kg)

Technical Specifications
