Ap1310-DC User Guide Page 11 of 13
8.5 DATA
CABLE
You can attach a suitable data cable terminated with a female D9 connector. As a guide the pinout for
a standard 9 way PC comm port (male) is given below.
D-9 Pin Name Function (refers to PC)
3 TxD Serial Data Output
2 RxD Serial Data Input
6 & 8 CTS & DSR Busy Input
5 SGND Signal Common 0V
8.6
EMC STATEMENT
The Ap1310-DC is fully EMC (Electro-Magnetic Compatibility) compliant and is CE marked
accordingly. A Declaration of Conformity, in accordance with the EMC Directive 89/336/EEC (and as
amended) is available from Able Systems on request. The Ap1310-DC also carries an automotive e-
mark that applies, provided the printer is installed in-line with the directive.
8.7 EMC
Caution
System EMC compliance remains the responsibility of the system designer. It is recommended that
screened cables are used; earthing arrangements will depend on the application. Further advice is
available from Able Systems on request.
