SPECIFICATIONS
Pickup Device 1/3'' SONY Super HAD CCD
Video Format NTSC or PAL
Scanning System
NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec
Picture Elements 768 x 494(NTSC) ; 752 x 582(PAL)
Horizontal Resolution 560TVL
Sensitivity 0.5Lux/F=1.2
S/N Ratio Over 48dB(AGC off)
Electronic Shutter 1/50(1/60)~1/100,000
Lens Type
Vari-focal lens, Auto Iris
f=2.9~10mm, F=1.2
f=3.8~9.5mm, F=1.2
f=9~22mm. F=1.6
*Lens models and availability vary in different regions
Back Light Comp. ON/OFF Switch
Auto Gain Control ON/OFF Switch
Flickerless ON/OFF Switch
Auto White Balance Yes
Gamma Correction 0.45
Video Output
2 video outputs
BNC 1.0Vp-p, 75ohm
Additional testing video output 1.0Vp-p, 75ohm
Sync. Mode Internal Sync
Power Source 12VDC/24VAC
Power Consumption
24VAC: 5VA max
12VDC: 3.5W max
Dimensions 108(O.D.) x 80(H) mm ; 4.3"(O.D.) x 3.2"(H)
Weight 0.3 kg ; 0.7lbs
Operating Temperature 0°C~40°C ; 32°F~104°F (20%~80% Humidity)
Certifications FCC/CE
