Air-cooled engine deck group – Exmark LAZER Z 103-0656 User Manual
Page 20
19
AIR-COOLED ENGINE DECK GROUP
Ref.
No.
Qty.
Part No.
Description
Req'd.
Ref.
No.
Qty.
Part No.
Description
Req'd.
1
1-643315 Baffle, Engine Cooler ............. 1
33
32128-33 Nut, whizlock 1/4-20 .............
5
2
1-303335
Plastic tie ............................. 1
34
1-633396 Clip, loom .56........................
1
3
1-523420
Bumper, rubber .................... 2
35
1-809076 Screw, M6-1.0 x 45mm
4
322-6 Screw, Cap 5/16x1 ¼
(Warner)
1
(23 hp & 25 hp Koh) ..................
2
5
1-633630
Grommet
(all clutches)
........... 2
32144-57 Screw, 5/16-18x1.75
6
1-603610
Wshr, spring disc
(all clutches)
. 2
(23 hp Kaw & 26 hp Koh) .......... 2
7
1-633615-03 Guard, rear engine ............... 1
36
1-323235 Washer, disc spring
8
1-633543-03 Strap, clutch
(all clutches)
....... 1
(23 hp & 25 hp Koh only)...........
2
9
103-0662
Clutch w/tie
(23HP)
................ 1
37
1-323236 Spacer ...................................
2
103-0665
Clutch w/tie
(25&26HP)
........... 1
38
1-633545 Spacer, Grommet
(all clutches)
. 2
10
1-633453
Spacer
(23 HP)
..................... 1
39
1-633988 Spacer, clutch anchor
(Warner)
. 1
1-633179
Spacer
(25 & 26 HP)
............... 1
40
3296-29 Nut, nyloc 5/16-18
(Warner)
....
1
11
1-634308
Shield, lift – subassy
(Koh)
.... 1
3296-29 Nut, nyloc 5/16-18
(Ogura)
......
2
103-1301
Shield, lift – subassy
(Kaw)
.... 1
41
3256-63 Washer, 3/16 std. ..................
6
12
103-1308
Shield, engine ...................... 1
42
∇
1-543232 Nipple, pipe 3/8 NPT
(Koh)
....
1
13
1-633300-03 Shield, lift
(Koh)
..................... 1
43
∇
1-303428 Elbow, 3/8 NPT
(Koh)
............
1
103-1304-03 Shield, lift
(Kaw)
..................... 1
44
322-14 Screw, 5/16-18 x 3.0
(Ogura)
..
1
14
1-634796
Shield (LH) - subassy
(Koh) ...
1
45
1-633082 Spacer, clutch anchor
(Ogura)…
1
103-0241
Shield (LH) - subassy
(Kaw)
.. 1
46
322-7 Screw, 5/16-18 ½
(Ogura)
.......
1
15
1-633301
Shield, heat
(Koh)
.................. 2
47
1-643179 Spacer, clutch
(Ogura)
............
1
103-0243
Shield, heat
(Kaw)
................. 2
48
1-641212 Clutch w/tie
(Ogura)
.................
1
16
1-633795-03 Baffle, engine (LH) ............... 1
49
1-643180 Keeper, clutch
(Ogura)
............
1
17
1-643313-03 Shield, muffler ..................... 1
50
1-807261 Key, ¼ x ¼ x 2.0
(Ogura)
........
1
18
1-644316
Shield (RH) - subassy
(Koh)….
1
51*
103-1594 Muffler,kit 26hp EFI Kohler ... 1
103-0242
Shield (RH) - subassy
(Kaw)…
1
103-1595 Muffler,kit 23hp Kaw ............. 1
19
1-523285
Clip, shield
(Koh)
................... 2
52
9266934 Screw, 5/16-18x.5
1-523285
Clip, shield
(Kaw)
................... 4
(23 hp Kaw & 26 hp Koh) ..........
2
20
1-633794-03 Baffle, engine (RH)............... 1
53
324-2
Screw, 7/16-14x.75 g5
21
322-19
Screw, 5/16-18x4
(Warner)
.... 1
(23 hp Kaw & 26 hp Koh) ..........
2
22
321-4
Screw, 1/4-20 x ¾ ................ 10
54
3253-6
Washer, Lock 7/16
23
1-613235 Washer
(Warner)
................... 4
(23 hp Kaw & 26 hp Koh) ..........
2
1-613235 Washer
(25 hp Ogura)
............ 5
55
33014-00 Nut, Hex M8 1.25
24
323-6
Screw, 3/8-16 x 1 ................. 8
(23 hp Kaw & 26 hp Koh) ..........
4
323-6
Screw, 3/8-16 x 1
(26hp Koh)…
9
56
1-805005 Washer, Lock 5/16hvy
25
³ 3212-10 Screw, 7/16-20x2 ½
(all clutches)
1
(23 hp Kaw & 26 hp Koh) ..........
4
26
1-803035
Rivet, 3/16 x ¼
(Koh)
............. 11
57
9
103-0152 Keeper, Clutch ..................... 1
1-803035
Rivet, 3/16 x ¼
(Kaw)
............ 13
58
1-653291 Gasket
(Koh)
......................... 2
27
3296-42
Nut, nyloc 1/4-20 .................. 6
1-653313 Gasket
(Kaw)
.......................... 2
28
1-643264-03 Bracket, guard top ................ 2
59
103-1513 Arrester,Spark (1.25) ............ 1
29
3256-2
Washer, 1/4 std .................... 4
(26 hp Koh EFI & 23 hp Kaw)
30
3256-3 Washer, 5/16 std
(all clutches).
... 1
60
103-1514 Clamp,Muffler (1.38)
............. 1
31
32128-20
Nut,whzlck 5/16-18
(Warner)…
1
(26 hp Koh EFI & 23 hp Kaw)
32
3290-357 Nut, whzlck 3/8-16 ................ 8
3290-357 Nut, whzlck 3/8-16
(26hp Koh)…
9
∇
Use a Teflon Pipe Sealant or equivalent on threads.
Use Pro-Lock, Nut Type (P/N 840022, .5ml tube) on clutch bolt.
*
The muffler for 23 & 25 HP Kohler units comes with the engine.
9
For 23 HP Kawasaki air-cooled units only
Exmark black touch up spray paint - gloss black
Kohler Replacement Parts List
Kawasaki Replacement Parts List
(Refer to Engine Owner’s Manual)
(Refer to Engine Owner’s Manual)
Description
Kohler Part No.
Description
Kawasaki Part No.
Engine Oil Filter
5205002
Engine Oil Filter
49065-2078
Air Precleaner
(23hp Engine) 2408302
Air Filter
11029-7002
(For 25hp Engine) 2408305 .........
Air Filter
(For 23hp Engine) 4708303
(For 25hp Engine) 2408303
(For 26hp EFI Engine) 2508301
Safety Filter (For 26hp EFI Engine) 2508304
