9
FRONT FRAME GROUP
Exmark red touch up spray paint - P/N 850337
∇
Components are standard on Kohler 26 HP EFI units & all 72” decks, they are an optional kit for other models
PN 103-0149.
Ref.
No. Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 1-632518-01 Frame wldmt, front 52” ....... 1 29 3217-11 Nut, 5/8-11 regular............. 8
1-632513-01 Frame wldmt, front 60”....... 1 30 1-633441 Swivel, deck mount............... 4
1-642046-01 Frame wldmt, front 72”....... 1 31 3256-7 Washer, 5/8 std flat ........... 4
2 302-19 Zerk, 1/4-28 straight ........... 5 32 1-633064 Spring, deck support (52” &60”) 2
3 103-1490-01 Floorpan ............................ 1 1-643015 Spring, deck support (72”) .. 2
4 1-633553 Pad, anti skid...................... 3 33 3218-6 Jam nut, 5/8-11.................. 4
5 1-634312 Lever w/grip ....................... 1 34 1-543513 Cap, grease ........................ 2
1-632324-03 Lever wldmt, lift ................. 1 35 1-543509 Bearing cone, tapered roller 4
6 1-633295 Grip, lift lever ...................... 1 1-543508 Bearing cup, tapered roller . 4
7 103-1500-03 Arm wldmt, deck lift ............ 1 36 1-543511 Seal, grease........................ 2
8 1-633325 Spring, compression .......... 1 37 1-642111-01 Caster wldmt........................ 2
9 3256-24 Washer, 3/8 SAE flat.......... 1 38 3296-51 Nut, 3/4-10 nylock................ 2
10 3296-39 Nut, nylock 3/8-16 .............. 5 39 1-633508 Washer, spring disk...... ....... 6
11 32151-103 E-ring .................................. 5 40 325-24 Screw
,
½-13x9 .....................2
12 1-633068 Arm, deck lift ...................... 2 41 1-811010 Plug ..................................... 2
13 3272-10 Cotter pin, 1/8 x 3/4 ............ 2 42 103-0069 Caster wheel assy ............... 2
14 1-808284 Clevis pin, 3/8 x 1 ............... 2 43 3296-45 Nut, 1/2-13 nylock (light thin) .. 2
15 1-633889-01 Plate, deck lift..................... 1 44 1-633959 Spacer, front caster ............. 2
16 1-632899-01 Plate wldmt, deck lift .......... 1 45 103-0063 Seal, bearing........................ 4
17 1-633082 Bushing, lift lever ................ 1 46 1-633585 Bearing cone........................ 4
18 1-633080 Bushing, lift lever ................ 1 47 1-633581 Spacer, bearing.. ................. 4
19 323-13 Screw, 3/8-16 x 2 3/4 ......... 1 48 103-0065 Wheel & tire assy ................ 2
20 1-633097 Hitch pin w/lanyard ............. 1 1-523009 Tire, 13x6.5-6 4 ply ............. 2
21 1-806005 Hairpin cotter (serv only) .... 1 103-0071 Wheel .................................. 2
22 323-9 Screw, 3/8-16 x 1 3/4 ......... 2 1-633584 Bearing cup.......................... 4
23 98-5975 Washer, 3/8 disc spring...... 12 49 ∇ 32128-20 Nut, whizlock 5/16-18……… 2
24 3290-357 Nut, whizlock 3/8-16 .......... 15 50 ∇ 1-543161 Pad, pedal............................ 2
25 323-6 Screw, 3/8-16 x 1 ............... 3 51 ∇
103-0147-01 Lever wldmt, deck lift ........... 1
26 323-7 Screw, 3/8-16X1 1/4 ........... 12 52 ∇ 1-643220 Strap .................................... 1
27 3256-29 Washer, 7/8 SAE flat.. ........ 4 53 ∇
322-7 Screw, 5/16-18x1 1/2 ........... 2
28 1-633096 Rod, deck lift....................... 2
