Connections
The water inlet and drain hoses, as well as the mains cable must be con-
nected beside the dishwasher as there is insufficient space behind the
appliance.
The plumbing and electrical installation example given below can only
be regarded as a recommendation.
Two 45° or Straight Connections,
Outer ø 19 mm, Length 30 mm
Double tap
Water drain
Water inlet
Water
drain
Water
inlet
Mains
cable
Mains
cable
Mains socket
