60” DECK GROUP
-5-
Item
Part No.
Description
Qty.
1 103-3184 Asm, Deck (109-4081-01) W/Decals ......1
2 3217-46 Nut, Hex 3/4-16 Heavy...........................3
3 3256-24 Washer, 3/8 SAE ...................................3
4 1-513208 Washer, Spring Disk ..............................1
5 1-303334 Washer, 5/16 Spring Disk.......................1
6 32128-20 Nut, 5/16-18 Whizlock ............................8
7 1-602913-01 Baffle Wldmt, Discharge.........................1
8 322-2 Screw, 5/16-18 x 5/8 ..............................5
9 1-603299 Roller, Antiscalp .....................................6
10 3290-357 Nut, 3/8-16 Whizlock ..............................12
11 109-6658 Nut, Nyloc 3/8-16 Flg .............................6
12 99-2842 Spacer ...................................................6
13 98-5975 Washer, 3/8 Spring Disk.........................13
14 103-9746 Asm, Jackshaft Housing W/Brgs ............1
15 109-2738 Chute, Discharge ...................................1
16 322-5 Screw, 5/16-18 x 1 .................................4
17 3296-29 Nut, 5/16-18 Nyloc .................................7
18 1-633084-01 Shield, Belt 60”.......................................2
19 1-323385 Knob, Belt Shield ...................................6
20 1-322110 Belt Guide Wldmt ...................................1
21 109-5958 Screw, Hex Flange 1/2-20......................3
22 323-12 Screw, 3/8-16 x 2 1/2 .............................2
23 1-303537 Stud, Belt Shield ....................................2
24 3256-3 Washer 5/16 Std Flat .............................6
25 1-323417 Washer, Rubber.....................................2
26 103-3330 Spring, Extension...................................1
27 322-6 Screw, 5/16-18 x 1 1/4 ...........................1
28 103-5677 Spacer ...................................................1
29 103-5693
Kit, Idler Arm (103-6528-01)
W/Bearings ............................................
1
30 106-7159 O-ring.....................................................2
31
302-40 Zerk, 1/4-20 90°. ....................................1
32 3256-4 Washer, 3/8 Std Flat ..............................2
33 3296-39 Nut, 3/8-16 Nyloc ...................................19
34 103-3504 Bearing, Spherical..................................2
35 109-2796 Pulley, Idler ...........................................2
36 3234-11 Bolt, 3/8-16 x 1 Whizlock........................1
37 1-633456 Bushing, Idler.........................................2
38 323-8 Screw, 3/8-16 x 1 1/2 .............................18
39 32128-37 Nut, 7/16-14 Whizlock ............................16
40 1-603805 Idler Pulley 5.06 O.D. V..........................1
41 1-633127 Belt, Blade Drive Deck ..........................1
Item
Part No.
Description
Qty.
42 1-633447 Chain ..................................................... 4
43
103-1898 Screw, 7/16-14 x 1 5/8 Sp...................... 8
44 103-3505 Seal, Double Lip .................................... 1
45 3217-11 Nut, 5/8-11 Hex...................................... 2
46 103-2802 Washer, Spring Disk .............................. 3
47 103-9076 Cutter Housing Complete....................... 3
48 323-6 Screw. 3/8-16 x 1................................... 4
49 109-1181 Strut Wldmt, Deck.................................. 2
50 103-2794 Sheave, Blade Drive .............................. 3
51 1-633029 Spherical Rod End................................. 2
52 327-11 Screw, 5/8-11 x 5................................... 2
53 3253-8 Lockwasher,5/8 Reg.Spring ................... 2
54 302-19 Zerk, 1/4-28 Straight .............................. 4
55 1-632199-01 Pin Wldmt, Deck Strut............................ 2
56 3219-6 Nut, 5/8-18 Hex...................................... 3
57S 103-9086 Kit, Spindle ............................................ 3
58 103-3046 Sheave, Jackshaft Double ..................... 1
59 103-2982 Key, 1/4 x 3/16 x 3/4 .............................. 3
60 1-643393 Jackshaft ............................................... 1
61 103-1330 Guard,
Bearing Top ............................... 3
62 103-8280 Housing W/Bearings .............................. 3
63 1-373034 Washer .................................................. 2
64 103-2535 Spacer,
Guard Bottom ........................... 4
65 103-6403 Blade, Notched ...................................... 3
103-6388 Blade, Low Lift ....................................... 3
) 103-6393 Blade, Mulching ..................................... 3
103-6383 Blade, Solid ........................................... 3
103-6398 Blade, Extreme ...................................... 3
66 103-1081 Asm, Strut Long..................................... 2
67 103-3249 Jackshaft Assy....................................... 1
68V 103-3258 Complete Deck Assy.............................. 1
69 103-2916 Guard, Top ............................................ 1
70 98-5961 Screw, 3/8-16 x 4 Gr 8 ........................... 1
71 103-3506 Seal, Single Lip...................................... 1
72 32120-10 Ring, Retaining ...................................... 2
73 103-3037 Bushing, Splined.................................... 3
74 109-2148 Asm, Discharge Chute ........................... 1
75 3256-82 Washer .................................................. 3
76 3230-22 Bolt, Carriage 5/16-18 x1 ....................... 3
77 109-0938-01 Hinge, Grass Discharge......................... 1
78 103-9792 Asm, Chain Deck ................................... 4
79 103-4051 Kit, Anti-scalp......................................... 6
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
)
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK604Q.
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade antisieze) between the jackshaft and
bearings, jackshaft and sheaves, spindles and bearings, spindles and sheaves, and under top bearing guard. DO
NOT use a copper or nickel based antisieze.
V Complete deck assembly excludes items #39, #42, #43, and #66 and includes mule drive belt from page 16.
Kit also includes items #13 & #33.
S Kit includes items #2, #21, #46, #59 & #73.
