WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electric shock or death.
• Before carrying out any work on the
electrical section of the appliance, it must be
disconnected from the mains electricity supply.
• Connection to a good ground wiring system is
absolutely essential and mandatory.
• Alterations to the domestic wiring system
must only be made by a qualified electrician
!
WARNING!
Fire Hazard
Failure to follow this advice may result in
overheating, burning, and injury.
• Do not use adapters, reducers, or branching
devices to connect this appliance to the mains
power supply.
!
WARNING!
Cut Hazard
Failure to use caution could result in injury.
• Take care: some edges are sharp.
IMPORTANT!
SAVE THESE INSTRUCTIONS
The models shown in this installation guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go
to our website www.fisherpaykel.com or contact your local Fisher & Paykel dealer.
WARNING!
To avoid hazard, follow these instructions carefully before installing or using this appliance.
z z
Please make this information available to the person installing the appliance—doing so could
reduce your installation costs.
z z
Save these instructions for the local inspectors use.
z z
This oven is to be installed and connected to the electricity supply only by an authorized person.
z z
If the installation requires alterations to the domestic electrical system, call a qualified electrician.
The electrician should also check that the socket cable section is suitable for the electricity drawn
by the oven.
z z
The oven must be grounded.
z z
Installation must comply with your local building and electricity regulations.
z z
This appliance must be installed and connected to the mains power supply only by a suitably
qualified person according to these installation instructions and in compliance with any applicable
local building and electricity regulations. Failure to install the appliance correctly could invalidate
any warranty or liability claims.
z z
If the power supply cable is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified person in order to avoid a hazard.
z z
A circuit breaker is recommended.
z z
Do not use adaptors, reducers or branching devices to connect the oven to the mains electricity
supply, as they can cause overheating and burning.
z z
Make sure the cavity is completely sealed with no gaps. This is to ensure the oven cooling system
functions correctly.
z z
The appliance must not be installed behind a decorative door in order to avoid overheating.
z z
Please take extra care not to damage the lower trim of the oven during installation. The trim is
important for correct air circulation and allows the door to open and close without obstruction.
The manufacturer does not accept any responsibility for damage resulting from incorrect
installation.
Electrical requirements
z z
Connect oven with copper wire only.
z z
Do not cut the conduit.
z z
A U.L. listed conduit connector must be provided at the junction box.
z z
Do not ground to a gas pipe.
z z
Do not have a fuse in the grounding or neutral circuit.
z z
Fuse both sides of the line.
z z
A time delay fuse or circuit breaker is recommended. If using a time delay fuse, then fuse both
sides of the line.
z z
Flexible armored cable from the appliance should be connected directly to the junction box.
z z
Connect directly to the fused disconnect (or circuit breaker box) through flexible, armored or
non-metallic sheathed, copper cable (with grounding wire).
z z
If codes permit and a separate grounding wire is used, it is recommended that a qualified
electrician determine that the grounding path and wire gauge are in accordance with local codes.
SAFETY AND WARNINGS
