11
D
ESCRIPTION
The ECHO product you have purchased has been factory pre-assembled for your convenience. Due to packaging
restrictions, some assembly of Models SHC-2100, SHC-2400 and HCA-2400 is required.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
CONTENTS LIST
MODEL
_____ 1 - Shaft Hedge Clipper Assembly ALL
_____ 1 - Shaft Assembly HCA-2400
_____ 1 - Power Head Assembly SHC-2400/HCA-2400
_____ 1 - Cutting Attachment Assembly HCA-2400
_____ 1 - Gear Housing Assembly
_____ 1 - Operator's Manual
ALL
_____ 1 - Hedge Clipper Safety Manual ALL
_____ 1 - Warranty Statement ALL
_____ 1 - Warranty Registration Card ALL
_____ 1 - 2-Stroke Oil Sample, 2.6 oz. ALL
_____ 1 - T-Wrench ALL
_____ 1 - 3mm Hex wrench SHC-2100/2400/HCA-2400
_____ 1 - 4mm Hex Wrench SHC-2100/2400/HCA-2400
_____ 1 - 8mm/10mm Wrench SHC-2400
_____ 1 - Shoulder Strap Assembly HCA-2400
_____ 1 - Front Handle Assembly HCA-2400
_____ 1 - Safety Glasses ALL
IMPORTANT ENGINE INFORMATION
ENGINE FAMILY : TEH021UB24RA
DISPLACEMENT : 23.6 cc
THIS ENGINE MEETS U.S. EPA PHI AND 1995 - 1999
CALIFORNIA EMISSION REGULATIONS FOR ULGE
ENGINES. REFER TO OWNER’S MANUAL FOR
MAINTENANCE SPECIFICATIONS AND ADJUST-
MENTS.
EMISSION CONTROL
The emission control system for this engine is EM (Engine Modification).
An Emission Control Label is located on the engine. (This is an EXAMPLE ONLY, information on label varies by engine
FAMILY).
