Power Wash 250™
©Elation Professionals® Los Angeles, Ca. - wwww.ElationLighting.com - Page 18
3.1 Adjust the DMX- Address (D001)
After applying power to the POWER WASH 250B™ the LED will display the
fixture’s current DMX address. If the fixture is not receiving a DMX signal the
display will flash continuously.
D001
To set or adjust a DMX address, please follow the procedure below:
1. Switch on the POWER WASH 250B™ and wait for the fixture reset process to
finished (' RESE ' will flash in the LED while fixture is in reset mode).
2. Press the Mode button to access the main menu. Toggle through the menu by
pressing the Up and Down buttons until the display shows D001 . Tap the enter
button to make changes to the address, the current three digit address will
immediately begin to flash.
3. While the current three-digit address is flashing, use the Up and Down buttons
to select adjust the address. Lock your new address into by pressing the Enter
button. After the new address has been successfully stored into the fixture’s
memory the LED will briefly readout
OK .
The DMX address is non-destructible and will remain in the fixture’s memory even
when the power has been switched off. Memory is backed-up and retained by an
internal power source with a five year shelf life.
3.2 The Test Program (TEST)
Test
The Test Program launched the fixture’s internal test mode. This function runs a
complete test procedure of all functions. Press Enter to launch the self-test or the
Mode button to cancel.
3.3 The Audio Program (AUDI
The Audio menu allows you to run a stand-alone audio program. This program
can run either fast (
AFST ) or slow ( Aslw ); Fast ( AFST ): When running in “fast”
mode every sound impulse will trigger a new step. ( Aslw ): When running in You
may run several fixtures together at once to achieve a synchronized light show
running to sound in a Master/Slave configuration. To run in a Master/Slave.
