User Manual
OPERATING YOUR SCANLITE
SCANLITE ON/OFF SWITCH AND MAINS PLUG
Before connecting the mains plug to the mains socket, ensure that the On/Off switch is in
position Off: “0” must be visible on the switch (to prevent arcing mains plug contacts).
Then connect the mains cable to the mains socket => the fan spins and the cooling system
is active.
Switch the halogen light on, press the On / Off switch to the
On position.
After using the SCANLITE, switch the halogen light off, but do not remove the mains plug
before the fan cooled down the temperature of the SCANLITE.
SCANLITE INTELLIGENT FAN COOLING AND OVERHEAT
PROTECTION
The fan speed is electronically controlled. Close to the on/off switch is a small LED, which
lights up in case of over heating. The overheat protection shuts the Halogen lamp down at
high internal temperature. After cooling down, the Halogen lamp switches on automatically
and the red LED turns off.
FITTING ACCESSORIES
1. Always switch the unit off before attaching accessories.
2. Disconnect the mains cable.
3. Mount the
SCANLITE Head to a tripod and lock the security screw.
4. Turn the locking ring of the reflector bayonet anticlockwise in OPEN position.
5. Insert an accessory and turn it clockwise until you hear it click into place.
6. Turn the locking ring clockwise to close the bayonet, indicated by the white mark on the
bayonet ring.
7. Check if the Reflector is correctly fitted.
8. Reconnect the mains cable and switch the unit on.
