16 English
Be
for
e y
ou s
tar
t
Before you start
• Do not use the induction cooktop to dry clothes.
• Never store flammable materials such as aerosols and detergents in the
drawer or cupboards under the induction cooktop.
• Users with Pacemakers or Active Heart Implants must keep their upper body
at least 1 ft. (30 cm) from the induction cooking zones when they are turned
on. If in doubt, you should consult the manufacturer of your device or your
doctor.
CAUTION
AFTER COOKING
• Do not touch the Induction elements until they have cooled down.
• The surface can stay hot for some time after cooking is complete. If you touch
the surface before it has had time to cool down sufficiently, you can burn
yourself.
• Immediately clean spills on the cooking area to prevent a tough cleaning
chore later.
• After you have activated elements on the cooktop, the internal fan may come
on for cooling purposes.
• The fan activation time may differ depending on the temperature of the
internal sensor. (10 minutes or 20 minutes)
• If you have cabinet storage directly above the cooking surface, make sure that
the items in the cabinet are infrequently used and can be safely stored in an
area subjected to heat. Temperatures may be unsafe for items such as volatile
liquids, cleaners, or aerosol sprays.
CAUTION
If the cooktop is installed above an oven, do not use the cooktop while the oven's
Self-cleaning function is on.
Location of the induction cooktop elements and controls
Cooking zones
07
01
03
02
04
05
06
01 Induction Left front 7", 1800 W with Power Boost 2300 W
02 Induction Left rear 7", 1800 W with Power Boost 2300 W
03 Induction Center 11", 2300 W with Power Boost 3800 W
04 Induction Right front 6", 1200 W with Power Boost 1800 W
05 Induction Right rear 7", 1800 W with Power Boost 2300 W
06 Control Panel
07 Wi-Fi communication area
NOTE
Do not put cookware on the Wi-Fi communication area.
