• For extractor versions (13A), connect the other end of the exhaust pipe to the flue.

For filter versions (13F), fit deflector F to the support and secure it to the bracket

supplied using 4 screws, then connect the exhaust pipe to the connection ring located

on the deflector.

• Fit the nuts with fixing hooks (14) supplied inside the top and bottom sections of the

flues at the rectangular slots. A total of 14 nuts must be fitted.

• Only for HI 8820/DI 8820:Fix the two bracket supplied with one screw each (15a)

• Join the two top sections of the flue to cover the support (15b) so that one of the slots

on the sections is situated on the same side of the control panel and the other on the

opposite side. Screw the two sections together with 8 screws and springs (4 each

side- see the plan diagram for joining the two sections - springs must be fixed

horizontally).

• Fix the top flue assembly to the support, near the ceiling, with two screws (16 - one

each side).

• Carry out electrical connection of control panel and bulbs (17).

• Join the two bottom sections of the flue covering the support (18) using 6 screws and

springs (3 each side, see the plan diagram for joining the two sections - springs must

be fixed horizontally).

• Insert the bottom section of the flue in its seat so that it completely covers the motor

compartment and electrical connection box, then ensure it from inside the hood using

two screws (19).

• Apply the 2 tabs (20 - supplied) to cover the fixing points of the bottom flue

(CAUTION! THE BOTTOM FLUE TABS ARE THE NARROWER AND

SHALLOWER ONES).

The wider and deeper tabs are those used for the top flue, and must be cut to size.

If necessary, slightly expand the tabs to ensure their adherence to the flue.

• Turn the mains power on again at the central electrical panel and check for correct

hood operation.
