24 English
C
ar
e and cleaning o
f the c
ookt
op
Care and cleaning of the cooktop
Burner cap
1. Match the burner caps to the burners by
size, and then re-install the caps on the
burner heads.
CAUTION
Make sure each cap is re-installed on the
correct burner head, is centered on the
burner head, and lies flat.
Burner cap
CAUTION
Make sure all burner components (heads
and caps) are reinstalled properly. They
will be stable and rest flat when correctly
installed.
Top Bottom NOTE
The precise simmer burner (RR) cap and
the inner Dual burner (Center) cap are
interchangeable.
NOTE
After installation of surface burners, check the ignition.
Incorrect placement of a burner head or cap will result in poor ignition or uneven
flames (as shown in the pictures).
