REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

INCLUDES THE FOLLOWING:

CARBURETOR -- C1U-K42

1

12520020560

SCREW

2

12534452130

1

COVER, DIAPHRAGM

1

12534207360

2

DIAPHRAGM, METERING

1

1

------------------

3

GASKET, METERING DIAPHRAGM

1

1

------------------

4

SCREW

1

12533942030

5

PIN, METERING LEVER

2

1

------------------

6

LEVER, METERING

2

1

------------------

7

SPRING, METERING LEVER

2

1

------------------

8

VALVE, INLET NEEDLE

2

1

------------------

9

CLIP

1

12532713930

10

SCREW

1

12534813930

11

LEVER, THROTTLE

1

12535020560

12

PLUG, WELCH

2

1

------------------

13

VALVE, THROTTLE

1

12531620560

14

SCREW

1

12531451230

15

SPRING, NEEDLES

2

12531942030

16

WASHER

2

12535307760

17

SCREW, IDLE NEEDLE

1

12531820560

18

LIMITER, MIXTURE

1

12532909860

19

NEEDLE, HIGH SPEED

1

12532020560

20

LIMITER, MIXTURE

1

12532908560

21

SHAFT, THROTTLE

1

12531706860

22

SPRING, THROTTLE RETURN

1

12531308560

23

PIECE, FRICTION

1

12537813930

24

SCREW, IDLE ADJUST

1

12533406860

25

SCREW

2

12531011610

26

RETAINER, PURGE PUMP

1

12536311610

27

PURGE, PUMP

1

12538146730

28

COVER, PUMP

1

12532411610

29

GASKET, PUMP

1

1

------------------

30

DIAPHRAGM, PUMP

1

1

------------------

31

SCREEN

2

1

------------------

32

NOZZLE, CHECK VALVE

1

12537607360

33

NOT AVAILABLE SEPARATELY

BODY, CARBURETOR

1

------------------

34

REPAIR KIT

1

12530020560

GASKET/DIAPHRAGM KIT

1

12530320560

Footnotes

1: Included In REPAIR KIT & GASKET/DIAPHRAGM KIT
2: Included In REPAIR KIT

99922202804

- 7 -

REVISED 10/08/07

Table of Contents

Part Number Index

PB-2100 Power Blower

Carburetor
