Electrolux RH30WC55GSB - Manual (Page 13)

13 13 13 13 13
Mounting the duct cover Mounting the duct cover Mounting the duct cover Mounting the duct cover Mounting the duct cover
t Position the duct cover over the mounted hood.
t Slide the bottom of the duct into the glass area.
t Position the top of the duct over the duct
mounting bracket. If a telescopic duct cover is
used, grab the upper part of the telescopic duct
cover, pull it and place it in the duct cover
mounting bracket.
t Secure the top of the duct with 2 assembly
screws provided.
t Secure the bottom of the duct with 2 assembly
screws provided.
Instal the grease filter and turn power on at service
panel. Check operation of the hood.
Installing the hood
