EHA-SRX
3. SPECIFICATIONS
Model Name EHA-SRX HD-SDI to HDMI Converter
Technical
SDI Standards
HD-SDI
Video Bandwidth 1.485Gbps
Video Support 720p @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p @25/30Hz
Input Signal HD-SDI: SMPTE 292M, 296M
Output Signal HDMI /HD-SDI
Input Connector 1x BNC [HD-SDI] 3G 75Ω inter-locked socket
Output Connector
1x HDMI Type A [19-pin female] ; 1x BNC [HD-SDI] 3G 75Ω
inter-locked socket
Mechanical
Housing
Metal case
Dimensions 77 (W) x 38 (H) x 117 (D) mm / 3” (W) x 1.5” (H) x 4.6” (D)
Weight 200g / 0.45lbs
Power Supply 12VDC
Power Consumption 2 W max.
Operation Temperature 0~50°C / 32~122°F
Relative Humidity
(20%~80% Humidity)
4. PACKAGE CONTENTS
- HD-SDI to HDMI Converter (x1)
- Accessory packet (x1)
- Power adaptor (x1)
- Printed Installation Guide (x1)
4
