EverFocus EHD320 User Manual
Page 11
6. View Angel Adjustment
The camera can be rotated 360°
horizontally, 140° vertical and 60° 3’rd
axis view angles (as shown in Figure 8). Adjust the proper camera view
angel as needed. If a vari-focal lens is used, you may adjust the focus
and zoom of the lens to bring the object in focus. Be sure to loosen the
locking screws on the lens before you do the adjustments.
Lens fixing Screws
Figure 8
8
