Elo TouchSystems 2125C - Manual (Page 33)

C-27
A P P E N D I X
C
C HAPTER 4
T
ECHNICAL
S
PECIFICATIONS
N OTE : All specifications are subject to change.
Touchmonitor Specifications
21" Touchmonitor Specifications
Picture Tube 21” (20” diagonal viewable image), 0.25mm dot pitch,
anti-static, anti-glare, and TCO treatment coated.
Maximum Resolution 1600 x 1200@85Hz
Deflection Frequency Horizontal: 30-107kHz
Vertical: 50-150Hz
Maximum Video Input Bandwidth 261 MHz
Display Area* Factory Setting: approx. 380mm x 285mm
Input Signal R.G.B. Analog, 15 pin D-sub, BNC optional
Input Voltage 100-240 VAC, 3.0A
Display Colors* Analog input; unlimited colors
Power Consumption 120 watts (typical)
Power Management Compliant with VESA DPMS signaling method.
Plug and Play Compatibility Compliant with VESA DDC 1/2B standards.
CRT Life Average operational CRT life is 12,000 hours to half
brightness.
*Dependent on video controller/card used .
