EUB-9701 Wireless N USB adapter
Version 1.3
12
8 Setup WLAN (EnGenius Config-Utility)
Prerequisite:
1. Your home/office environment should have a wireless LAN Access Point
(AP) that is available for your use.
2. You should readily have the (security keys) to connect those Wireless LAN
Access Points (AP)
Configuration utility will first automatically link with the Wireless AP if there is no
security key required. If the connection is successful, a message will appear on
taskbar.
Following steps guides you to initially setup a wireless network connection.
Notice the EnGenius configuration utility on the taskbar
Hovering the mouse cursor briefly over “EG” icon will show status as follows…the
current status indicates that Config utility has automatically connected to an
Access Point named NKSP.
Right click on “EG” icon will open up a menu as shown below
