Preassemble a 4 inches
(
10.2cm
) el
bow to the next
4
inch
es
(
10.2cm
)
duct section, and secure all
joints with duct tape. Be sure that the
male end of the elbow faces AWAY from
the dryer.
Insert
t
he elbow/duct assembly
through the side opening and press it
onto the adapter duct.
Secure
in place with duct tape. Be sure that
t
he male end of the duct
protrudes 1.5 inches
(
3.8cm
)
to connect the remaining ductwork
.
Duct tape the knockout removed to the opening in the back of the dryer.
2
.
Press
the tabs on
the knockout and carefully
remove the knockout for
the
desired vent opening.
Press the
adapter
duct
onto the blower housing of the dryer as shown
.
Option 2: Bottom venting
1 ''
(
3.8 cm)
Elbow
Duct
Tape
Knockout
Adapter
Duct
3
.
Insert the 4 inches (10.2cm
)
elbow through the rear
opening and press
it
onto
t
he adapter duct
.
Be sure that
t
he male end of the elbow faces down through hole in the
bottom
of
the dryer.
Secure in place with duct
tape
.
Duct tape the knockout removed to the opening in the back of the dryer.
Duct
Tape
1
/
2
Elbow
