REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

INCLUDES ITEM 2

TANK, FUEL

1

A350000041

1

SPACER

2

13104528230

2

SCREW 5X15

2

90027505015

3

3X5X195mm BULK OPTION: 90014

PIPE, FUEL - 3X5X195mm

1

1

13201007530

4

GROMMET, FUEL

1

V137000030

5

CLIP

1

13201309820

6

STRAINER, FUEL

1

13120507320

7

3X6X110mm BULK OPTION: 90017

PIPE, RETURN - 3X6X110mm

2

1

13201006460

8

VALVE, CHECK

1

A356000030

9

3X5X70mm BULK OPTION: 90014

PIPE , VENT - 3X5X70mm

1

1

13131239130

10

INCLUDES ITEM 12-13

FUEL TANK CAP ASY

1

13100455530

11

GASKET, FUEL CAP

1

13101655830

12

CONNECTOR, FUEL CAP

1

13105156030

13

Footnotes

1: BULK OPTION: 90014
2: BULK OPTION: 90017

99922203278_150i/07

- 9 -

REVISED 06/21/06

Table of Contents

Part Number Index

HC-150i HEDGE CLIPPER

Fuel System
