Echo HC-150I User Manual
Page 5
REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
INCLUDES ITEM 2-17
SHORT BLOCK
1
SB1067
1
BOLT 5X22
2
90016205022
2
CYLINDER
1
A130000420
3
GASKET, CYLINDER
1
1
V100000080
4
INCLUDES ITEMS 6-10
PISTON KIT
1
P021001111
5
RING, PISTON
2
A101000000
6
PIN, PISTON
1
10001311520
7
CIRCLIP, PISTON PIN
2
10001504630
8
SPACER, PISTON PIN
2
10001408960
9
BEARING, NEEDLE
1
10011305930
10
CRANKSHAFT ASY
1
A011000230
11
INCLUDES ITEMS 13-17
CRANKCASE KIT
1
------------------
12
OIL SEAL
2
10021242030
13
DOWEL PIN
2
10021503930
14
GASKET, CRANKCASE
1
1
10024242030
15
BEARING, BALL
2
9403536201
16
BOLT 5X28
3
90016205028
17
GASKET KIT
1
P021004710
18
COIL, IGNITION
1
A411000120
19
BOLT 4X20
2
90016204020
20
TUBE
1
V475002200
21
BUSHING
1
15611004920
22
CAP, SPARK PLUG
1
15901201620
23
TERMINAL, SPARK PLUG CAP
1
15901103432
24
SPARK PLUG -- BPM-8Y
1
15901019830
25
CANADA MODELS
SPARK PLUG -- BPMR-8Y
1
A425000000
26
LEAD, IGNITION
1
16202152830
27
GROMMET
1
15611404920
28
FLYWHEEL
1
A409000150
29
WASHER, CLUTCH
1
17501405360
30
PLATE, CLUTCH
1
17501904920
31
INCLUDES ITEMS 33-35
CLUTCH ASY
1
17500006560
32
SPRING, CLUTCH
2
17501805960
33
SHOE, CLUTCH
2
17500905131
34
HUB, CLUTCH
1
17501604920
35
COVER, CYLINDER
1
A160000151
36
BOLT 4X20
2
90016204020
37
SCREW 4X8
1
9110704008
38
LABEL, CAUTION - HOT
1
89016006361
39
Footnotes
1: Also Included In GASKET KIT
99922203278_150i/07
- 5 -
REVISED 06/21/06
HC-150i HEDGE CLIPPER
Engine, Short Block, Ignition, Clutch, Cylinder Cover
