Earthquake • MiniMe User Manual 14
Specification
Amplifier Output
320 Watts (4.6-Ohm impedance)
High Cut Filter
35Hz 100Hz adjustable. The crossover can
be bypassed by rotating the crossover
frequency control fully clockwise.
Frequency Response
28Hz 175Hz
Power Line Voltage
110-120C~AC / 60Hz / 180 WATTS
Dimensions (HxWxD)
10-1/4” x 9-3/4” x 11-3/8”
260.4mm x 247.7mm x 289mm
Weight
16.46Lbs
Finish
Piano Black
Output Levels
Greater than 108dB peak SPL (includes room
gain) from 25Hz to 90Hz.
Input Sensitivity For Full Output
240mVrms from left input with volume control
at 0dB, 90mVrms with volume control fully
clockwise.
Input Impedance
8.2 kilo-Ohm Line-level inputs
32-Ohm Speaker-level inputs
Driver
8” high-power with extra large magnet and
long throw mechanical design yield very high
back emf. The result is extraordinarily high
operating efficiency that is, more acoustic
output for each watt of input.
Internal System Gain
42dB from left input jack to speaker with the
Bass Level control at 0dB, 54dB with the control fully
clockwise.
