Eaton 9155 Accessories
Accessories
Order Number
Description
Dimensions
H x W x D (in)
Unit Weight
(lb)
Powerware Hot Sync
124100017-001
9155 Parallel Cabinet
24.0 x 20.3 x 2.2
57.3
103004336
Powerware HotSync CAN Bridge Card
-
-
Notes: Up to three 9155 UPS and up to four 9355 UPS (available Fall 2005) UPSs can be paralleled with the Parallel Cabinet.
Extended Battery Module (EBM) or Cabinets (EBC)
103004192-5501
9155 and 9355 EBM 64 (2-high)
32.2 x 12.0 x 30.2
480
103004193-5501
9155 and 9355 EBM 96 (3-high)
47.8 x 12.0 x 30.2
710
Notes: up to four EBM 64 cabinets or three EBM 96 cabinets can be added to each 8-15 kVA UPS for extended runtime.
Seismic Mounting Kit
103004194-5501
Seismic Kit, Rated Zone 4, UL Tested, Performance rating based on NEBS GR-63-CORE Standard Vibration Test
Fits both
2- & 3-high models
136
Maintenance Bypass Module (MBM)
BPE20MBB1A
Wall-mounted Maintenance Bypass Module for 9155
21 x 14 x 6.75
31
Eaton 9155 Parallel System Start Up
OSTUP9155P10CX
9155 8-10 kVA 2 or 3 Unit Parallel
OSTUP9155P15CX
9155 12-15 kVA 2 or 3 Unit Parallel
103004626
9155 Parallel System 2 unit upgrade kit (includes Can Bridge Cards, Procedures, and Parallel User's Guide)
103004627
9155 Parallel System 3 unit upgrade kit (includes Can Bridge Cards, Procedures, and Parallel User's Guide)
Connectivity Options
116750221-001
ConnectUPS-X Web/SNMP/xHub Card
05146288-5501
ConnectUPS-MX SNMP/Modem Card (9155 only)
1035425-5591
Modbus Card
05146508-5501
USB Card
1018460
Relay Interface Card (AS/400 Compatible)
103003055
Industrial Relay Card
116750224-001
Environmental Probe (requires ConnectUPS Web/SNMP card)
Spare Parts
106711155
9155 Spare Parts Kit "A"
Upgrades
103004195
9155 8 kVA to 9155 10 kVA
103004196
9155 12 kVA to 9155 15 kVA
Power Distribution Module (PDM) with Mechanical Bypass Switch
Optional Receptacle Panels
Breaker
Voltage
Phase
(4) 5-15R
15A
120V
1
(4) 5-20R UL
20A
120V
1
(4) 6-15R
15A
208V
2
(4) 6-20R
20A
208V
2
(4) L5-15R
15A
120V
1
(2) L5-20R*
20A
120V
1
(2) L5-30R*
30A
120V
1
(2) L6-15R
15A
208V
2
(2) L6-20R*
20A
208V
2
(2) L6-30R*
30A
208V
2
(2) L14-20R*
20A
120/208V
2
(2) L14-30R*
30A
120/208V
2
Blank panel
* The combined quantity of these locking receptacle plates must not exceed four.
