Breaker protected

and unswitched

15 amp outlet

Protection "On"

Indicator

Digital Voltmeter

Readout

Power switch

On / Off

Pull out lights
ON/OFF
HI/LOW
switch

Pull out lights

20 amp Breaker
15 amp Breaker

Back View PD11LVSP

Back View PD11P, 11VP, 11LP, 11LVP

Protected

"Always On” 20 amp Outlets

Stage 1 Stage 2 Stage 3 Stage 4

Protected

"Always On” 20 amp Outlets

Easy 4-step bulb replacement. Use 120 volt 4 watt bulb (Christmas tree bulb). PD11LP, 11LVP, 11LVSP

1. Twist cap clockwise

3. Replace bulb

2. Release bulb & socket

4. Replace socket, snap on cap, turn cap counter-clockwise

Front View PD11LVP Model Shown

3 pin terminal block for re
sequential operation of un
