The PD11SS is a sequential four step/stage power up/down conditioned power distribution unit. It is designed to protect
electronic equipment that requires a time-delayed start-up, particularly when high in-rush current can potentially damage
audio, video, or computer equipment at power up.
PD11SS Features:
• Microprocessor monitored sequential power distribution system
• Four power up/down steps or stages of distributed and conditioned power
• Four pre-set power up/down intervals of 1, 5, 10 or 30 seconds
• Optional manual settings for up to 240 seconds between intervals
• One dual 15 amp U-grounded outlet per stage
• One dual 15 amp "always on" U-grounded outlet
• Full 15 amps, 1800 watts capacity per unit
• 12-gauge, 3-prong, 6-foot, 15-amp power cord
• Protected "always on" 15 amp AC power outlet on the front panel
• Total unit 15 amp outlet circuit breakers located on front panel
• Three-stage spike and surge protection
• EMI/RFI filtration
• Watch dog circuitry with "Go/No Go" L.E.D. display
• One rack space high
• One year limited warranty
Other Features:
• Remote control operation
Access to remote feature is internal to three PC board mounted screw terminals for 3-wire hook-up.
Specifications:
Dimensions 19" L x 10" D x 1 3 /
4
" H
Weight 10 lbs.
Quality Finish Black powder coated chassis, black anodized aluminum front panel
Electrical 120V, 50/60 Hz, single phase
Max. amps 15/unit
Max. watts 1800/unit
Max. front outlet 15 amps
Spike/surge protection Line to neutral, neutral to ground, line to ground
Clamping level 200V peak
Response time 1 nanosecond
Max. surge voltage 6000V
Max. surge current 12,000 amps
Max. spike energy 450 joules total
Noise attenuation Transverse > 35 dB, 1.5 kHz to 200 MHz
Certification ETL listed
Breaker protected and unswitched
15 amp outlet
Protection "On"
Indicator
Sequential
On / Off
Power switch
On / Off
1 thru 4 steps/stages in sequential power up/
down 1, 5, 10, 30 second pre-sets 15 amp breaker
Protected
"Always On” Outlets
Stage 1 Stage 2 Stage 3 Stage 4
3
3 pin terminal block for remote
sequential operation of unit
