| PCU Specifications
PCU Specifications
Specification
Description
Dimensions
Width: 33 inches (838 mm)
Depth: 16 inches (406 mm)
Height: 10.5 inches (267 mm)
Electrical
220/240 V, 20 A male plug
Requires a NEMA L6-20 receptacle
The supplied cable has three conductors:
Green = Earth/ground
Black = AC Phase (208 – 240 VAC)
White = Neutral
Plate size
Minimum 9 inches (229 mm)
Maximum 24 × 30 inches (610 × 762 mm)
Plate type
PET or aluminum; 0.005 to 0.012 inch (0.0127 to
0.0305 mm) thick
Temperature range
122 to 482 °F (50 to 250 °C)
Temperature accuracy
±3.6 °F (2 °C) over the plate area
Speed/dwell time
5 to 24 inches (127 to 610 mm) per minute
Weight
40 lb (18 kg)
Console controls
Heater ON/OFF
Temperature set
Temperature display
Speed set
