Model EGPI4322L4

In keeping with our policy of continuing product improvement, Elkay reserves the right to change

product specifications without notice.

This specification describes an Elkay product with design, quality and functional benefits to the

user. When making a comparison of other producers’ offerings, be certain these features are not

overlooked.

ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.

These sinks comply with ANSI Standard A112.19.3M.

These sinks are listed by the International Association

of Plumbing and Mechanical Officials as meeting the

requirements of the Uniform Plumbing Code.

I

A

P

M

O

UPC

F

O

UNDED 19

26

GENERAL

Highest quality Gourmet sink bowls are seamlessly drawn of

#18 gauge, type 304 (18-8) nickel bearing stainless steel.

Self-rimming.
DESIGN FEATURES

Bowl Depths: 10" (large bowl) and 6-1/2" (small bowl),

recessed 1/2" below outside of sink.

Coved Corners: 1-1/2" radius.

Finish: Exposed surfaces are polished and hand blended to a

lustrous Lasting Beauty satin finish with a highlighted inside top

radius on the sink bowls.

Underside: Fully protected by heavy duty Sound Guard

®

under-

coating to prevent condensation and deaden sound.
OTHER

Drain Opening: 3-1/2".

Faucet Holes: 1, 3 or 4 holes.

Cutting Board: CBP1116 cutting board surface furnished with

each sink.
OPTIONAL ACCESSORIES

Rinsing Baskets: LKRB1614 and LKERBSS.

Cutting Surface: CBP1319.

Gourmet Cuisine Centré

®

Double Bowl Sink with Ribbed Area

Models EGPI4322L and EGPI4322R

®

SPECIFICATIONS

Cutout in

Countertop

Inside Each Bowl

Ribbed

(1

1

/

2

" Radius

Number of

Minimum

Ship.

Model

Overall

Left

Right

Area

Corners)

1

1

/

2

" Dia.

Cabinet

Wt.

Number

L

W

L

W

D

L

W

D

Length

L

W

Faucet Holes

Size

Lbs.

EGPI4322L

43 22

16

18

10

7

1

/

2

12

7

/

8

6

1

/

2

12

7

/

8

42

3

/

8

21

3

/

8

1, 3 or 4

48

35

1

/

2

EGPI4322R

43 22 7

1

/

2

12

7

/

8

6

1

/

2

16

18

10

12

7

/

8

42

3

/

8

21

3

/

8

1, 3 or 4

48

35

1

/

2

SINK DIMENSIONS (INCHES)*

*

Length is left to right. Width is front to back

.

Model EGPI4322R4

4" 4"

5"

6-1/2"

1-3/4" R

1-1/8" R

1-3/4" R

2-13/16"

10"

43"

2"

2"

18"

22"

2"

2"

16"

21-3/4"

FINISH

DIRECTION

7-1/2"

14-3/8"

12-7/8"

3-3/8"

2"

18"

2"

12-7/8"

1-1/4"

Model EGPI4322R4 Illustrated

4"

4"

5"

6-1/2"

1-3/4" R

1-3/4" R

1-1/8" R

2-13/16"

10"

43"

2"

2"

18"

22"

2"

2"

16"

21-3/4"

FINISH

DIRECTION

7-1/2"

14-3/8"

12-7/8"

3-3/8"

2"

18"

2"

12-7/8"

1-1/4"

Model EGPI4322L4 Illustrated

4"

4"

5"

3 HOLE CONFIGURATION

MODEL EGPI4322R3

5"

ONE HOLE CONFIGURATION

MODEL EGPI4322R1

4"

4"

5"

3 HOLE CONFIGURATION

MODEL EGPI4322L3

5"

ONE HOLE CONFIGURATION

MODEL EGPI4322L1
