Removing and Installing an I/O Board or Blank
Panel
W
The FOX 4G Matrix 14400 fiber optic I/O boards
output continuous invisible light, which may be
harmful and dangerous to the eyes; use with caution.
• Do not look into the rear panel fiber optic
cable connectors or into the fiber optic cables
themselves.
• Plug the attached dust caps into the optical
transceivers when the fiber optic cable is
unplugged.
N
As factory configured, the fiber optic I/O boards are
configured as either 100 percent singlemode or 100 percent
multimode, but you can remove a fiber optic transceiver
module (one input and one output) of one transmission
mode and replace it with a block of the other transmission
mode.
You can mix transmission mode transceiver modules on
a fiber optic I/O board, provided that you ensure that
each fiber cable and connected devices are the appropriate
transmission mode for the transceiver module.
Typically, singlemode fiber has a yellow jacket and
multimode cable has an orange jacket.
N
For proper cooling and air flow, boards and/or blank panels
should be installed in all locations during normal switcher
operations.
N
See "A note on I/O boards", on page 2-2, to understand the
different arrangement of connectors on the I/O boards.
Circuit boards can be replaced for fault correction. They also
can be added or removed to increase or decrease the I/O
configuration (size) of the switcher.
Remove and replace and I/O board or blank panel as follows:
N
The I/O boards are hot-swappable. You do not need to
power down the switcher to remove an I/O board.
1
.
For an I/O board
, disconnect any connected cables.
2
.
Rotate the left and right knurled knobs to completely
loosen the captive screws.
3
.
Gently pull on the knurled knobs/captive screws to loosen
the board or panel from the backplane.
4
.
Slide the board or panel out of the chassis (next page).
