ACCESSORIES
Order Number
Description
Dimensions H x W x D (in)
Unit Weight
(lb)
Powerware Hot Sync
124100017-001
Powerware 9155 Parallel Cabinet
24.0 x 20.3 x 2.2
57.3
103004336
Powerware HotSync CAN Bridge Card
-
-
Notes: Up to three Powerware 9155 UPS and up to four Powerware 9355 UPS (available Fall 2005) UPSs can be paralleled with the Parallel Cabinet. Each Powerware 9155 UPS and Powerware 9355 UPS must have a
Powerware Hot Sync CAN Bridge Card installed in the second X-Slot communication bay.
Extended Battery Module (EBM)
103004192-5501
Powerware 9155 and Powerware 9355 EBM 64 (2-high)
32.2 x 12.0 x 30.2
480
103004193-5501
Powerware 9155 and Powerware 9355 EBM 96 (3-high)
47.8 x 12.0 x 30.2
710
Notes: up to four EBM 64 cabinets or three EBM 96 cabinets can be added to each UPS for extended runtime.
Seismic Mounting Kit
103004194-5501
Seismic Kit, Rated Zone 4, UL Tested, Performance rating
Fits both 2-
136
based on NEBS GR-63-CORE Standard Vibration Test
& 3-high models
Powerware 9155 Maintenance Bypass Module (MBM)
103004184-5501
UPS-Mounted, Maintenance Bypass Module
16.5 x 12.0 x 7.0
15
BPE14MBB1A
Wall-mounted, Maintenance Bypass Module
21.0 x 14.0 x 6.75
31
Powerware 9155 Parallel System Start Up
OSTUP9155P15KCX
Powerware 9155 8-10 kVA 2 or 3 Unit Parallel
OSTUP9155P10KCX
Powerware 9155 12-15 kVA 2 or 3 Unit Parallel
103004626
Powerware 9155 Parallel System 2 unit upgrade kit (includes Can Bridge Cards, Procedures, and Parallel User's Guide)
103004627
Powerware 9155 Parallel System 3 unit upgrade kit (includes Can Bridge Cards, Procedures, and Parallel User's Guide)
Connectivity Options
103002974-5501
ConnectUPS-X Web/SNMP/xHub Card
05146288-5501
ConnectUPS-MX SNMP/Modem Card (9155 only)
103002510-5501
Modbus Card
05146508-5501
USB Card
05146447-5501
Multi-Server Card (9155 only)
1018460
Relay Interface Card (AS/400 Compatible)
103003055
Industrial Relay Card
103003637-5501
Environmental Probe (requires ConnectUPS Web/SNMP card)
Spare Parts
106711155
Powerware 9155 Spare Parts Kit "A"
106711169
Powerware 9355 Spare Parts Kit "A"
Upgrades
103004195
Powerware 9155 8 kVA to Powerware 9155 10 kVA
103004196
Powerware 9155 12 kVA to Powerware 9155 15 kVA
103004657
Powerware 9355 10 kVA to Powerware 9355 15 kVA
Power Distribution Module (PDM) with Mechanical Bypass Switch
Optional Receptacle Panels
Breaker
Voltage
Phase
(1) L15-30R
30A
208V
3
(1) L21-20R
20A
208/120V
3
(1) L21-30R
30A
208/120V
3
(2) 5-15R
15A
120V
1
(2) 5-20R
20A
120V
1
(2) 6-15R
15A
208V
2
(2) 6-20R
20A
208V
2
(2) L5-15R
15A
120V
1
(1) L5-20R
1
20A
120V
1
(1) L5-30R
1
30A
120V
1
(2) L6-15R
15A
208V
2
(1) L6-20R
1
20A
208V
2
(1) L6-30R
1
30A
208V
2
(1) L14-20R
1
20A
120/208V
2
(1) L14-30R
1
30A
120/208V
2
(2) IEC 320 C13 (120V)
20A
120V
1
(2) IEC 320 C19 (120V)
20A
120V
1
Blank panel
Note: Maximum of eight panels per PDM (Powerware 9155). Maximum of four panels per PDM (Powerware 9355).
1. The combined quantities of single-locking receptacle panels must not exceed five per PDM.
