Step four: define the location of the new device, Software setup, cont’d – Extron electronic Extron IPL T S4 User Manual
Page 28
IPL T S Series Interfaces • Software Setup
Software Setup, cont’d
3-8
Step four: define the location of the new device
Global Configurator allows you to keep track of the devices on
your audio/video network by creating a custom tree of folders
in which you can place and organize your audio/video devices.
This GlobalViewer Tree can be up to eight levels deep and have
multiple folders in each level.
To move your newly added device to a Location folder, with the
Add Device dialog box still open:
1
.
Click the New Location folder icon above the GlobalViewer
Tree window.
2
.
Enter a unique location name for the new folder and keep
the new location folder selected.
3
.
Click OK. The new device is added to the selected location
folder and the Add Device dialog box closes.
