Page 23

23
IMPORTANT
Chain and guide bar gauge size must be identical. Use Bar/Chain combinations shown in table
above.
IMPORTANT
If your kick guard is damaged or lost, contact your Echo dealer for a replacement. For the name
of the Echo dealer nearest you, Call: 1-800-432-ECHO (3246) or on the web at www.echo-usa.
com.
Refer to your Chain Saw Safety Manual for kick guard application information.
C
hain
anD
g
uiDe
b
aR
C
ombinations
The following combinations may be used on CS-341.
WARNING
Use of replacement saw chain and/or guide bar other than that specified, or operation without the “tip guard” in place,
may cause severe kickback resulting in serious injury.
Only use saw chain designated as, “LOW-KICKBACK,” that meets the ANSI B175.1-2000 Standard when tested on
the representative sample of chain saws below 3.8 C.I.D., and the Echo guide bar specified.
4. Idle Speed Adjustment.
• Turn “idle” speed adjustment screw (B) CW until the
saw chain begins to move, then turn the screw CCW
until saw chain stops moving. Turn screw CCW an
additional 1/4 turn.
5. Accelerate to full throttle for 2-3 seconds to clear
excess fuel from engine then return to idle. Accelerate
to full throttle to check for smooth transition from idle
to full throttle. If engine stops or stalls after full warm
up return the unit to your authorized ECHO dealer for
adjustment.
6. Install grommet cover (A) over “H” and “L” limiter
needles.
*Reduced nose radius symmetrical bars (OREGON name — Double Guard)
MODEL
BAR
LENGTH
LOW KICKBACK
GUARD BAR
LOW KICKBACK SAW CHAIN
KICK GUARD
BAR P/N
CHAIN P/N
LINKS
TYPE
PITCH
GUAGE
ECHO P/N
(OEM P/N)
CS-341
12”
12A0CD3745
91VG45CQ
45
91VG
3/8”
0.050
2894901
28949
14”
14A0CD3752
91VG52CQ
52
16”
16A0CD3757
91VG57CQ
57
