4
Push
Push
( fig.2)
Insert the exposed ends of the joint connectors
into the short (vertical) frame and align the four
corners so that they meet at perfect right angles
5. After making sure that all four corners join at right angles to form a perfect rectangle, fasten the
four angles together by using the (x8) joint screws included. (see fig.3)
4. edge of the screen as seen below. (see fig.4)
Screw
( fig.3)
