LBC VGA HR
VGA Cable: 9-pin D Female to 15-pin HD Male LBC
LBC Mac HR
Mac 15-pin D Cable: 9-pin D Female to 15-pin D Male LBC
LBC SUN HR
13W3 Workstation Cable: 9-pin D Female to 13W3 Male LBC
Interface Cables
(continued)
For RGB 202 Rxi and Other Universal Interfaces with 9-pin D Inputs
I n t e r f a c e s — I n t e r f a c e c a b l e s
LBC - Laptop Breakout Cables
Laptop Breakout Cables for 9-Pin Interfaces
desCription
Extron LBC - Laptop Breakout Cables allow for a direct connection from a laptop, notebook,
or any computer without a local monitor to any 9-pin Extron interface, such as the RGB 202 Rxi.
This cable uses Extron 14 Conductor Cable. Because an LBC is simply a direct signal path from
the computer's video output to the interface's input, all LBCs are 3 feet (0.9 meters), 6 feet
(1.8 meters), or 12 feet (3.7 meters) in length.
model Version desCription part # msrp
LBC VGA HR/3 3' (90 cm) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-224-02 $ 90
LBC VGA HR/6 6' (1.8 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-224-01 $ 110
LBC VGA HR/12 12' (3.6 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-224-03 $ 150
model
Version desCription part # msrp
LBC Mac HR/3 3' (90 cm) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-363-03 $ 90
LBC Mac HR/6 6' (1.8 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-363-01 $ 110
LBC Mac HR/12 12' (3.6 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-363-04 $ 150
model
Version desCription part # msrp
LBC SUN HR/3 3' (61 kHz) (90 cm) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-04 $ 120
LBC SUN HR/6 6' (61 kHz) (1.8 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-01 $ 140
LBC SUN HR/12 12' (61 kHz) (3.6 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-05 $ 180
LBC SUN HR/3 3' (71 kHz) (90 cm) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-06 $ 120
LBC SUN HR/6 6' (71 kHz) (1.8 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-02 $ 140
LBC SUN HR/12 12' (71 kHz) (3.6 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-07 $ 180
LBC SUN HR/3 3' (81 kHz) (90 cm) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-08 $ 120
LBC SUN HR/6 6' (81 kHz) (1.8 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-03 $ 140
LBC SUN HR/12 12' (81 kHz) (3.6 m) .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-413-09 $ 180
