INSTALLING OPTIONAL LOUVER
Attention: Remove protective film on brass louver before
installation.
Attention: The optional top louver has (4) mounting tabs.
The optional bottom louver has (2) clearance holes.
1. Remove (2) Phillips screws that attach upper, panel
front to casing top.
2. At the top, leading edge of upper, panel front push down
and outward to remove upper, panel front.
3. Remove (2) Phillips screws that attach lower, panel
front to casing bottom.
4. At the top, leading edge of lower, front panel push up
and outward to remove lower, front panel.
OPTIONAL LOUVERS
INSTALLATION
INSTRUCTIONS
Optional Model
Louver Number
FBL-36BR-2 VFFB-36D
FBL-36BP-2
FBL-36BL-2
FBL-42BR-2 VFFB-42D
FBL-42BP-2
FBL-42BL-2
5. Align and insert (4) mounting tabs on optional top
louver with (4) slots on casing top. Push downward to
lock the optional top louver into position.
6. Tighten one provided 1/2" screw into optional bottom
louver. Partially tighten second provided 1/2" screw
into optional bottom louver. Insert tightened 1/2" screw
in optional bottom louver into bottom of fireplace.
7. Push and pivot optional bottom louver into bottom of
fireplace. Complete tightening of second 1/2" screw
into bottom of fireplace.
8. Place magnets at top of one inch flanges that bottom
louver rests against when closed.
9. Installation of optional louvers is completed.
