4
1.) INTRO Indicator – Appears when Intro playback mode is selected.
2.) RAND (Random) Indicator – Appears when Random playback mode is
selected.
3.) PROG (Program) Indicator – Appears when programming tracks or playing
programmed tracks.
4.) VOL (Volume) Indicator – Appears when pressing VOLUME + /– buttons.
5.) Track Number/Volume Level Display – Shows the track which is being played,
and the total tracks on the disc. Also shows the volume level (0 to 32) when
VOLUME +/– buttons are pressed.
6.) Repeat 1/ALL Indicators – Appears when the Repeat playback mode is
selected.
7.) Battery Level Indicator – Bars indicate battery level.
8.) Anti-Skip Protection Indicator – Flashing icon indicates Anti-Skip Protection
is activated.
9.) CD-RW Indicator – Lights when playing CD-RW disc.
10.) Time Display – Shows elapsed time of the track being played and total playing
time of the disc.
LCD DISPLAY INDICATORS
5 4 6 7
10 8
2
1
9
J-ASP
3
