3 TARGET PROGRAM AND DEBUGGING

EPSON

S1C33 FAMILY DEBUG MONITOR

OPERATION MANUAL

10

3 Target Program and Debugging

This chapter describes precautions for debugging using the debug monitor.

3.1 Notes for Creating Target Programs

Follow the instructions below when creating the target program to be debugged:

Since the debug monitor uses the debugging exception of the CPU, addresses 0x0 to 0xF of the built-in RAM area
are used as the vector and stack for processing debugging exceptions. Therefore, the target program cannot use this
area. Furthermore, do not use addresses 0x10 to 0x2F.

Wh e n d eb ug gi ng t he t ar g e t p ro gr a m b y wr i ti ng i n t he RA M o r Fl as h me mor y o n t he t ar g e t b oa r d, ma p t he
program to that address.

Th e d eb ug mo ni to r d oe s n ot a ll ow f or c e d b re a k f un c ti on s s uc h a s k ey b re a k s. Fo rc e d b re a k f un c ti on s s ho ul d b e
ma de i n t he t ar g e t p ro gr a m u si ng a k ey i np ut i nt er r u pt o r a n NMI i np ut . Se tt in g a h ar d wa r e PC b re a k i n t he
interrupt processing routine makes it possible to execute a forced break.

3.2 Parameter File for Debugging

A debug-parameter file is required to start the debugger. Create the file according to the memory configuration of
the target system. When using the debug monitor, the debugger ignores all the settings for the ICE emulation
memory.
When using a Flash memory, specify it as a RAM.

Example: "dmt33004\sample\33104_m.par"

CHIP

33104

; chip name (33XXX)

IROM

1000

; internal ROM is 80000 to 80FFF

FOPT

0000

; f option size

PRC VER

00 ff

; allow any PRC board

PRC STATUS

****************

; allow any PRC board status

MPU

; 0xC00000 external boot address

VER

1

; this file version

; Emulation memory allocation (max 8 areas, 1MB/area, 1MB boundary)

EMROM

c00000

cfffff

; external ROM 1MB

; Map allocation (max 31 areas, 256bytes boundary)

RAM

0

7FF

; internal RAM area 2KB

IO

40000

4ffff

; internal IO area 64KB

RAM

200000

2fffff

; external FLASH 1MB

RAM

600000

6fffff

; external SRAM 1MB

EROM

c00000

cfffff

; external ROM 1MB

; Stack area except internal RAM area (max 8 areas, 256bytes boundary)

STACK

600000

6fffff

; external stack area 1MB

END
