pecIfIcatIons
MODELS -------------------------------------------------- SRM-230, SRM-230S
Length ------------------------------------------------------- 1795 mm (70.7 in.)
Width -------------------------------------------------------- 250 mm (9.84 in.)
Height ------------------------------------------------------- 250 mm (9.84 in.)
Weight (dry) w/Cutter Head (SRM-230) --------------- 5.1 kg (11.2 lb.)
Weight (dry) w/Cutter Head (SRM-230S) -------------- 4.9 kg (10.8 lb.)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Bore ---------------------------------------------------------- 32.2 mm (1.27 in.)
Stroke -------------------------------------------------------- 28.0 mm (1.10 in.)
Displacement ----------------------------------------------- 22.8 cc (1.39 cu. in.)
Exhaust ------------------------------------------------------ Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor--------------------------------------------------- Zama diaphragm w/purge pump
Ignition System -------------------------------------------- Flywheel magneto, transistor control ignition type
Spark Plug -------------------------------------------------- NGK BPMR-8Y (Gap 0.65 mm (0.026 in.)
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ---------------------------------------------- 50 : 1 Power Blend X™ ISO-L-EGD (ISO/CD 13738) and
J.A.S.O. M345- FC/FD, two-stroke, air-cooled engine oil.
Gasoline ----------------------------------------------------- Use 89 Octane unleaded. Do not use fuel containing methyl
alcohol, more than 10% ethyl alcohol or 15% MTBE. Do not use
alternative fuels such as E-15 or E-85.
Oil ------------------------------------------------------------ Power Blend X TM Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 0.58 lit. (19.6 US fl. oz.)
Starter System ---------------------------------------------- Automatic Rewind Starter
Clutch-------------------------------------------------------- Centrifugal Type
Vibration Isolated System -------------------------------- Rubber cushion on engine mount (heavy duty). Rubber grip on
front handle.
Operating Rod ---------------------------------------------- 25.0 mm aluminum tube
Drive Shaft (SRM-230) ----------------------------------- 6.35 mm (1/4 in.) flexible shaft
Drive Shaft (SRM-230S) --------------------------------- 7 mm (1/4 in.) steel shaft
Gear Case Ratio -------------------------------------------- 1.4:1
Rotating Direction ----------------------------------------- Counter Clockwise; viewed from top
Cutter Head ------------------------------------------------- Nylon line head (2-line) with .095 Crossfire™ Line capacity 6 m
(20 ft.)
Handle ------------------------------------------------------- Front - Loop and right rear handle with rubber grip
Shoulder Harness ------------------------------------------ Optional
Idle Speed --------------------------------------------------- 2,400 - 3,000 RPM
Clutch Engagement Speed ------------------------------- 3,800 RPM
Wide Open Throttle Speed (W.O.T.) with
Nylon Line Head ------------------------------------------- 8,500 - 10,500 RPM
Wide Open Throttle Speed (W.O.T.) with Blade ----- 9,500 - 11,500 RPM
IMPORTANT
This spark ignition system complies with the Canadian standard ICES-002.
