6 EN
INSTRUCTIONS
Thank you for purchasing this Olympus product.
To ensure your safety, please read this
instruction manual before use, and keep it
handy for future reference.
Switching the focusing method
Slide the focus ring 1 in the direction of the
arrow to switch the focusing method.
A : AF/MF
* MF is possible in the camera settings.
B : MF
* AF does not work if the focus ring position is
set MF position ( B ).
Autofocus stops while the L-Fn button 2 is
pressed.
Notes on Shooting
• When using a flash, flash light may be blocked
by the lens body, lens hood, etc.
• The focus distance may change when the
focusing method is switched from MF to AF/MF
and then back to MF. Readjust the focus
distance.
• The distance indicator is intended as a guide
only.
Main Specifications
Mount : Micro Four Thirds mount
Focal distance : 7 – 14 mm
(equivalent to 14 to 28 mm
on a 35 mm camera)
Max. aperture : f2.8
Image angle : 114.2° – 75.4°
Lens configuration : 11 groups, 14 lenses
Iris control
: f2.8 to f22
Shooting range : 0.2 m (7.9 in.) to
)
(infinite)
Focus adjustment : AF/MF switching
Weight
: 534 g (18.8 oz.)
(excluding cap)
Dimensions : Max. dia. Ø 78.9 (3.1 in.) ×
length 105.8 mm (4.2 in.)
Lens hood : Built-in type, not removable
Filter : Cannot be attached
* Specifications are subject to change without any
notice or obligation on the part of the manufacturer.
