EN-10

ENGLISH

1

Reverse and attach the

hood, keeping tripod
collar foot aligned with
the hood lock knob.

2

Insert the assembly with

the bottom of the tripod
collar foot in a corner of
the case.

Q

Be sure to attach the lens caps before putting the lens
in the case.

Q

Fit the assembly into the hollows inside the case.

3

Fit the deepest hollow in

the cushion over the lens
cap.

Q

Ensure that the cushion fi ts snugly with no gaps.

Q

Be sure to use the cushion even if the teleconverter is not
inserted.

4

Insert the teleconverter

with its rear cap in the
hollow in the cushion
and cover it with the net.

R

The lens can be inserted with the teleconverter attached.

Using the Lens Case
