background image

25741-0-0309

Page 22

Attention: When ordering parts, it is very important that part number and description of part coincide.

USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INjURY OR DEATH.

PARTS LIST

Index

Number

Part Number

description

VfSuR18(N,P)

VfSuR24(N,P)

VfSuR30(N,P)

1

23256

23276

23290

Rear Cover Plate

2

23245

23272

23286

Grate Leg Welded Assembly

3

24553

24553

24553

Venturi Shield

4

R3624

R3624

R3624

Pilot Assembly - Nat Only

4

R3623

R3623

R3623

Pilot Assembly - LP Only

5

24732

24719

24736

Burner Assembly (Includes Index Nos. 3 & 6) - Nat Only

5

24514

24515

24516

Burner Assembly (Includes Index Nos. 3 & 6) - LP Only

6

R5674

R5674

R5674

Venturi Tube Assembly - Nat Only

6

R9691

R9692

R9692

Venturi Tube Assembly - LP Only

7

R5676

R5676

R5676

Air Shutter - Nat Only

7

R5676

R5695

R5695

Air Shutter - LP Only

8

P302

--

--

Orifice #3.0 mm - Nat Only

8

P245

--

--

Orifice #50 - LP Only

8

--

P296

--

Orifice #3.1 mm - Nat Only

8

--

P265

--

Orifice #49 - LP Only

8

--

--

P303

Orifice #30 - Nat Only

8

--

--

P297

Orifice #1.9mm - LP Only

9

P253

P253

P253

Fitting, Orifice Angled

10

23249

23249

23249

Valve Bracket

11

R3626

R3626

R3626

Valve - Nat Only

11

R3625

R3625

R3625

Valve - LP Only

12

23250

23250

23250

Tubing Assembly

13

R2423

R2423

R2423

5/16 Male Connector

14

23251

23251

23251

Tubing Assembly - Nat Only

14

23263

23263

23263

Tubing Assembly - LP Only

15

R7063

R7063

R7063

Pilot Regulator - Nat Only

16

20116

20116

20116

Tubing Assembly - Nat Only

17

23252

23274

23288

Cover Plate Assembly

18

R9028

R9028

R9028

On/Pilot/Off Extension Knob

19

R9027

R9027

R9027

Hi/Lo Extension Knob

20

R3436

R3436

R3436

Remote/Off/On Switch

21

R2313

R2313

R2313

Piezo Igniter

22

R3435

R3435

R3435

Wire Assembly

23

R5668

R5668

R5668

12” Wire Ignitor

N/S

15999

15999

15999

Rockwool (Ember Material)

N/S

11788

11788

11788

Decorative Rock/Lava Rock (2 Required)

N/S

R2809

R2809

R2809

Damper Clamp
