EverFocus Mini Box Camera EQH5102 - Manual (Page 6)

EQH5102
1080p
Mini
Box
Camera
2
2.
Overview
No.
Name
Descriptions
1
HDcctv
Output
Connects
to
a
HD
device
using
a
75
Ohm
BNC-­‐type
coaxial
cable.
2
OSD
Menu
Joystick
Use
the
joystick
to
configure
the
settings
in
the
OSD
menu.
3
Screwless
Terminal
Strip
Connects
to
a
12VDC
power,
RS-­‐485
and
MD
(Motion
Detect)
source.
4
Power
LED
Glows
red
then
power
is
present.
5
Grounding
Stud
Ensuring
a
good
grounding
when
used.
6
Test-­‐Out
Connects
to
a
SD
CVBS
monitor
for
setting
aim
and
focus.
3.
Installation
3.1
Lens
Installation
and
Adjustment
You
can
install
either
a
CS-­‐mount
or
a
C-­‐mount
lens
into
the
camera.
It
is
recommended
to
use
a
lens
with
aperture
ratio
of
F/1.2
or
lower.
Please
refer
to
the
following
reference
steps.
CS-­‐Mount
Lens:
1. Remove
the
cover
cap
from
the
camera
body.
2. Install
the
lens
into
the
camera
body.
3. Adjust
the
lens
using
the
Focus
/
Zoom
Screws.
