EQH5102
1080p
Mini
Box
Camera
10
CAM
TITLE
Switch
to
On
and
then
enter
the
submenu
to
set
up
a
camera
name
displayed
on
the
screen.
RS-­‐485
Use
the

and

buttons
to
select
ID,
BAUDRATE,
PROTOCOL
and
ID
DISPLAY.
The
default
of
protocol
is
EVF-­‐1
(EverFocus).
Version
Press
to
display
the
firmware
version
of
the
camera.
DOUT
There
are
4
options
including
1080p
30FPS
NTSC,
1080p
25FPS
PAL,
720p
60FPS
NTSC
and
720p
50FPS
PAL
Language
Select
a
language
for
the
OSD
text.
Options
include
English,
French,
German,
Simplified
Chinese,
Korean
and
Japanese.
6.
Specifications
Camera
Pickup
Device
1/3”
Panasonic
2.1
megapixel
Color
Progressive
CMOS
sensor
Pixels
1920(H)
x
1080(V)
Resolution
Digital:1080p(30/25),
720p(60/50)
Sensitivity
Color:
0.4
lux,
BW:
0.1
lux,
Color
DSS:
0.1
lux,
BW
DSS:
0.025
lux
Digital(HDcctv
Output):
BT.1120,
HDcctv/HD-­‐SDI:
BNC
connector
Video
Output
Analogue(Test
Out):
NTSC/PAL
CVBS(w/o
WDR):
BNC
connector
S/N
Ratio
More
than
50
dB
(AGC
OFF)
Lens
DC/Manual
AGC
0-­‐20
steps
Shutter
Speed
AUTO/MANUAL(1/25(30)~1/60,000sec)
