582571 (GUWHOEWOOZ) Tilting Chilltherm Kettle
40 gal – 208 V
582573 (GUYHOEWOOZ) Tilting Chilltherm Kettle
40 gal – 480 V
Item No. ___________________________________
Unit to be Electrolux Electric Chilltherm self contained Cook & Chill
Kettle 40 gallon capacity with integrated stirrer (optional). Electric
characteristics to be ___208 V or ____480 V three phase. Boil, chill,
store and reheat food without frequent filling and emptying operation.
All
stainless steel construction, full jacket including heat insulated
external paneling. One piece deep drawn cooking vessel in 316
type
stainless steel. Unit shall include the possibility to install
integrated stirrer with left and right rotation (to be ordered as an
accessory). Unit shall be floor mounted on two consoles with four
adjustable
stainless steel feet. Unit shall include motorized variable
tilting of pan and fully insulated and counterbalanced closing lid.
Cooking temperature and cooking time can be precisely set through
state of the art control panel. Food sensor temperature built into
base plate permits precise temperature cooking.
Covered by Electrolux Platinum Star ® Service Program two-year
parts and one-year labor warranty, installation star t-up and
performance check-up after one year from installation.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
High Productivity Cooking
Electric Cook & Chill
Kettles– 40 gal
Main features
• Chilltherm kettle includes three different chilling programs:
• 1 step program: chill
• 2 step program: cook&chill
• 2 step program: chill&cook.
• Chilltherm kettle includes an integral agitator (to be ordered as option) and
cooling jacket.
• External cooling system is required. Available through a 3rd party supplier.
• The cooling system has to provide between 290 - 871 US gal./hour
(depending on the vessel size) of ice water at 37.4 °F at the kettle interface
• Round, tilting kettle is suitable to cook, sauté, poach or steam all kinds of
produce.
• Produce is uniformly heated in the base and side walls of the kettle by
steam hot water by an external jacket.
• Kettle shall be full jacketed including additional heat-insulated external
paneling.
• Cooking vessel (one-piece deep drawn) in 316 stainless steel (11 gauge)
featuring directional pouring lip. Double-jacket in 316 stainless steel (18
gauge) designed to operate at a pressure of 11.6 psi.
• The lid, mounted on the cross beam of the unit, shall be counterbalanced
by a special hinge that remains open in all positions.
• Lid is double-lined, insulated in 304 stainless steel.
• Integrated stirrer with left and right rotation (20 rpm). Stirrer to be ordered
as optional accessory.
• Steam-source: self-contained with a booster injecting steam directly into
double jacket.
• Controls are IPX5/NEMA4 water resistance certified.
• Actual cooking/holding temperature can be precisely set through the
control panel.
• Cook time settings visible through the digital display
• Pressure in double-jacket visible through digital display.
• Built -in food temperature sensor for precise control of cooking process.
• A SOFT setting for a gentle heat input, for delicate products thus avoiding
undesired spillage.
• A HOLD setting where the food is initially cooked then held at a pre-set
temperature.
• Firmly fitting insulated cover to reduce cooking time and save energy costs.
• Ergonomic: unique ratio vessel diameter and height; motor-assisted tilting.
• Offset tilting axle for convenient pouring height.
• Large directional pouring lip.
• Closed heating system – no waste of energy.
• Added safety: external heat-insulated paneling.
• Smooth large surfaces, easy access for cleaning.
• All pan internal surfaces ground and polished.
• Kettle vessel tilts over 90° for complete emptying/cleaning.
Optional Accessories
• Strainer for tilting kettles
• Grid stirrer + scraper for 40 gal kettles
