Essick Air FAD242 User Manual

High capacity axial fan evaporative cooler

background image

Model Series

FAD242
FAD248

Circle the model of your cooler and record
the serial number below.

Read Carefully All Of This Manual Before
Installing The Unit

Encierre con un circulo el modelo de su
enfriador y escribe el número de serie
abajo.

Lea Con Cuidado Todo Este Manual Antes De
Instalar La Unidad

Serial #

Número de Serie

110497

12-09

High Capacity

Axial Fan

Evaporative Cooler

Table Of Contents

Safety Instructions ......................................................................... 1
Operation ........................................................................................ 1
Installation Instructions .................................................................. 2
Maintenance Section .................................................................... 2-3
Electrical Wiring Diagrams .............................................................. 3
Troubleshooting .............................................................................. 4

Warranty ......................................................................................... 4
General Specifications (Especificaciones Generales) ..................... 5
Motor Specifications (Especificaciones Del Motor) ....................... 5
Parts List - Blower Section (Lista De Piezas) ............................ 6-7
Parts List - Wet Section (Lista De Piezas) .................................. 8-9
Spanish (Instrucciones en Español) ........................................... 9-12

Read And Save These Instructions

Safety Rules

1. Read instructions carefully.
2. Disconnect all electrical service that will be used for the unit before

you begin the installation.

3. Electrical hook up should be done by a qualified electrician, so that

all electrical wiring will conform to your local standards.

4. For a maximum safety precaution, make sure cooler cabinet is

properly grounded to a suitable ground connection.

5. Cooler must be connected to proper line current, voltage and cycle,

as stamped on cooler motor and pump motor specification plate.

Operation

To eliminate delivery of hot air when starting cooler, Start the pump
without the blower for the first few minutes, then turn on the blower
motor.

These coolers may be used without water for ventilation purposes.
When outside air is cool (for example, at night) or when humidity is
high the water pump can be turned off.

6. This unit must be installed at a height of 10 feet or greater from the

floor.

7. Always Disconnect Power before performing any maintenance.
